Polyimide Dots, 1/2in, 2000 Pieces/Roll

Hisco #:8258-1-2DOTS-12719

MFG #:8258-1-2DOTS

Available to Order - 0 on Hand

Manufacturer Estimated Lead Time When Not In Stock: 7 days

Minimum Order QTY: 5
Item must be ordered in multiples of 5

The CGS Tape 8258-1-2DOTS tape consists of a polyimide film and silicone adhesive designed for high temperature masking applications, including the protection of printed circuit board gold finger contacts during wave soldering, It is use in electrical insulation applications meeting class H requirements.

The CGS Tape 8258-1-2DOTS Features:

Thin and conformable enabling masking of uneven surfaces
Wide operating temperature range up to 500 °F
Excellent electrical insulation
Removes cleanly without adhesive residue after exposure to heat/chemical

The CGS Tape 8258-1-2DOTS Specifications:

Series: 8258
Product Type: Film Tape
Backing Material: Polyimide Film
Adhesive Material: Silicone
Material Category: Plastic
Color: Amber
Primary Color: Amber
Width: 1/2in
Thickness: 2.5mil
Adhesion Strength: 25oz/in
Tensile Strength: 30lb/in
Elongation at Break: >55%
Resistance Properties: Insulation Resistant Temperature Resistant Acid Resistant Oil Resistant Solvent Resistant
Applications: Mask for Protection of Gold Fingers of Printed Circuit Boards During Wave Solder or Solder Dip Process, Release Surface in Fabrication of Parts Cured at Elevated Temperatures, Widely Used for Electrical Insulation on Transformer, Motor, Coils, PCB Making
Maximum Operating Temperature: +500°F
