30MHz Single Channel Arbitrary Function Generator with pulse generator, modulation

30MHz Single Channel Arbitrary Function Generator with Pulse Generator, Modulation

• Model MFG-2130M
• 30MHz single channel arbitrary function generator
• 25MHz frequency pulse generator
• Modulation / sweep / burst/ frequency counter
• Earth ground isolation design among I/O terminals and instrument chassis
• Built-in medical and automotive electronic waveforms
• True point by point output arbitrary waveform function
• Sample rate 200MSa/s
• Waveform length 16k points
• Amplitude resolution 14bits

The output channels of MFG-2100 models include one single-channel 10M/20M/30M/60MHz ARB generator; one 25MHz pulse generator; one 160MHz or 320MHz RF signal generator (MFG-2160MF/MFG-2160MR) and one power amplifier (MFG-2120MA only).

The AFG channel of the MFG-2100 series outputs sine, square, and triangle, etc. The series features true point-by-point output arbitrary waveform characteristics of 200 MHz sample rate, 100MHz waveform repetition rate, 14 bit resolution, and 16k point memory depth. Some models provide various modulation methods such as AM/FM/PM/FSK/PWM, Sweep, Burst, Trigger, 150MHz Frequency Counter. Synchronized dual channel models provide correlated functions, including synchronization, delay, sum, and coupling. RF signal generator, a complete AFG signal source (including ARB), features various modulations, Sweep, and digital modulations such as ASK and PSK and its sine wave frequency is up to 320MHz. A full-function pulse generator with 25 MHz is equipped to all models and its pulse width, rise edge time, fall edge time are adjustable that can be applied as trigger signals. Independent input/output power amplifier with 20W, 10dB, DC-100KHz bandwidth, and distortion less than 0.1% can be applied to the audio application.

In The Box

• Single channel function generator
• Quick Start Guide
• CD-ROM with MFG Software
• User Manual
• GTL-101 BNC alligator test lead (x1)
